We have created the reference JPS16-S in our "Wood trim trails" range. This module is accessible from 12 years. It can accommodate up to 2 users.

The size of the module is: 6.29 m wide, 0.14 m. deep, 1.00 m. high. The free fall height (FFH) is 0.70 m.

3 sports activities

Balancing x1
Jumping x1
Running x1


Age range: 12+
Number of users: 2 users
FFH : 0.70 m
Size: 6.29 x 0.14 x 1.00 m

Equipment installation

Number of installers: 1
Installation time: 01:00:00
Concrete volume: 0.15 m3
Surface: 27.50 m2
Total weight: 49.96 kg
Weight of the heaviest element: 8.24 kg


The products in our catalogues all comply with current European standards and are TÜV approved. Our website offers many additional configurations for which Proludic certifies compliance.
Side view
Side view
View from above
View from above


The vertical 95mm square post

The vertical 95mm square post are made of laminated timber, which have not been treated with chrome or arsenic. Splinter-free, the laminate provides great strength and dimensional... stability. The posts are protected from wear and tear caused by fungi and insects. The posts are protected by injected polyamide caps. Read more

The panels

The panels are 21mm plywood panels made up of layers of birch. The surface is coated with a film of non-slip phenolic resin.

The fixings

The fixings are made of stainless or plated steel and protected by anti-vandalism polyamide caps.
