We have created the reference J1120 in our "Slides" range. This module is accessible from 2 years. It can accommodate up to 3 users.
The size of the module is: 3.60 m length, 2.05 m width, 3.30 m. high. The free fall height (FFH) is 1.00 m.
Specifications
| Age range: | 2+ |
| Number of users: | 3 users |
| FFH : | 1.00 m |
| Size: | 3.60 x 2.05 x 3.30 m |
Equipment installation
| Number of installers: | 2 |
| Installation time: | 05:00:00 |
| Concrete volume: | 0.20 m3 |
| Surface: | 22.00 m2 |
| Total weight: | 150.70 kg |
| Weight of the heaviest element: | 20.20 kg |
Environmental Indicators
Repairability
9.29 /10
Certification
The products in our catalogues all comply with current European standards and are TÜV approved. Our website offers many additional configurations for which Proludic certifies compliance.
Materials
The 125mm diameter posts are made of painted galvanised steel, ensuring robustness and durability. The caps are made of injection moulded polyamide.
The tubes are made of 40mm diameter stainless steel, guaranteeing lasting durability and reliability of the equipment.
The platform is 21mm plywood panels made up of layers of birch. The surface is coated with a film of non-slip phenolic resin.
The coloured panels are made from a 13mm thick compact material (HPL). Robust in construction, it has excellent weather and vandal resistance properties.
The Kayak slide is made of rotomoulded polyethylene.
Injection moulded polyamide fixings connect the posts with the platforms and the various play features. They are non-toxic, flameproof and U.V. resistant. The thickness of the polyamide... makes the equipment both strong and vandal resistant. Read more
The fixings are made of stainless or plated steel and protected by anti-vandalism polyamide caps.
